Product Description

Incepted in 1996, we hold expertise in providing superior quality Solid Core Drop Out Fuse Set. Used as secondary backup against fault in transformers, this fuse set is suitable to protect the system from over current. This fuse set is manufactured using superlative quality components and advance technology under the strict vigilance of our professionals. The offered Solid Core Drop Out Fuse Set is made available for clients in several technical specifications at market leading price.

Features:

Application

The dropout (swing out) fuse is an expulsion type and its main function is to protect Transformers on rural distribution network. It is also particularly useful for inaccessible Sub-stations where indication of fusing is of advantage.

Construction

The Drop out fuse set has single pole construction and shall be suitable for Vertical mounting. Each pole consist of galvanized steel base, insulators of reputed make, copper alloy DO Top & Bottom contacts and fuse carrier’s top & bottom contacts, epoxy extruded fiber fuse carrier. DO fuse bottom contact and rotateable latch is specially designed in such a way that it hangs the fuse carrier on blowing of fuse element. Top and bottom contacts are provided with overtravel limit. Ferrous parts are hot dip galvanized and non-ferrous parts are heavily tinned to withstand weather. Fuse element is of EC grade copper of appropriate size to complete the current path from top post to bottom post.

Features

Operation

On blowing of fuse element, the latch will release from top contact and the fuse carrier hangs down vertically on the bottom contact. This is advantageous for locating the fault as hanging fuse carrier is noticeable from distance and this save times which otherwise would be taken in investigation. Lift out the fuse carrier by means of the insulated operating rod from ground level, first rewire the fuse element at the bottom contact of fiber barrel, pass through the fuse element from fiber barrel, put the latch in on position, tied the fuse element on top contact of fiber barrel tightly and screw the wing nut. Put the barrel in bottom contact of DO unit with the help of insulated operating rod & swing up the carrier and thus remake the circuit.

Installation

It can be mounted vertically on channel based on two-pole structure. Install three phases of DO Fuse on structure.

TECHANICAL SPECIFICATIONS:
